Technical Data
| Data/Model | B/BA 13 | B/BA 15 | L13 | L15 | L16 |
|---|---|---|---|---|---|
| A (mm) | 1300 | 1500 | 1300 | 1500 | 1500 |
| B (mm) | 1200 | 1600 | 1200 | 1600 | 1600 |
| C (mm) | 1900 | 2300 | 1900 | 2300 | 2300 |
| D Working Radius (mm) | 2000 | 2500 | 2000 | 2500 | 2500 |
| Dimensions Diagram (click to view) | View | View | View | View | View |
| Travelling Frame Width (mm) | NA | NA | 1000 | 1000 | 1200 |
| Bucket Breakout Force (kg) | 1500 | 1800 | 1500 | 1800 | 1800 |
| Rotation Angle | 180 | 180 | 180 | 180 | 180 |
| Pump Max Delivery (ltr/min) | 13 | 15 | 13 | 15 | 15 |
| Working Pressure (bar) | 180 | 180 | 180 | 180 | 180 |
| Tank Capacity (ltr) | 15 | 25 | 25 | 25 | 25 |
| Digging Bucket (mm) | 250-400 | 250-400 | 250-400 | 250-400 | 250-400 |
| Weight With Bucket (kg) | 250 | 290 | 280 | 300 | 320 |
| Min Tractor’s Weight (kg) | 650 | 750 | 750 | 800 | 850 |
| Min Power Requirements (hp) | 13 | 15 | 13 | 15 | 15 |
| Data/Model | B/BA 13 | B/BA 15 | L 13 | L 15 | L 16 |
|---|---|---|---|---|---|
| A (mm) | 1300 | 1500 | 1300 | 1500 | 1500 |
| B (mm) | 1200 | 1600 | 1200 | 1600 | 1600 |
| C (mm) | 1900 | 2300 | 1900 | 2300 | 2300 |
| D Working Radius (mm) | 2000 | 2500 | 2000 | 2500 | 2500 |
| Dimensions Diagram (click to view) | View | View | View | View | View |
| Travelling Frame Width (mm) | NA | NA | 1000 | 1000 | 1200 |
| Bucket Breakout Force (kg) | 1500 | 1800 | 1500 | 1800 | 1800 |
| Rotation Angle | 180º | 180º | 180º | 180º | 180º |
| Pump Max Delivery (ltr/min) | 13 | 15 | 13 | 15 | 15 |
| Working Pressure (bar) | 180 | 180 | 180 | 180 | 180 |
| Tank Capacity (ltr) | 15 | 25 | 25 | 25 | 25 |
| Digging Bucket (mm) | 250÷400 | 250÷400 | 250÷400 | 250÷400 | 250÷400 |
| Weight With Bucket (kg) | 250 | 290 | 280 | 300 | 320 |
| Min Tractor’s Weight (kg) | 650 | 750 | 750 | 800 | 850 |
| Min Power Requirements (hp) | 13 | 15 | 13 | 15 | 15 |
