Technical Data
| Model | 50 TIX | 55 TIX | 60 TIX | 65 TIX | 70 TIX | 75 TIX | 80 TIX | 85 TIX | 90 TIX | 100 TIX |
|---|---|---|---|---|---|---|---|---|---|---|
| A (mm) | 2100 | 2200 | 2500 | 2600 | 2700 | 2800 | 3000 | 3100 | 3500 | 4200 |
| B (mm) | 1900 | 1900 | 2300 | 2300 | 2500 | 2500 | 2700 | 2700 | 3100 | 3850 |
| C (mm) | 2800 | 2800 | 3200 | 3200 | 3500 | 3500 | 3700 | 3700 | 4200 | 4950 |
| D Working Radius (mm) | 2900 | 2950 | 3270 | 3320 | 3500 | 3550 | 3800 | 3850 | 4000 | 5100 |
| Dimensions Diagram (click to view) | View | View | View | View | View | View | View | View | View | View |
| Travelling Frame Width | 1400 | 1600 | 1600 | 1800 | 1800 | 2000 | 1800 | 2000 | 2000 | 2000 |
| Bucket Breakout Force (kg) | 2300 | 2300 | 2600 | 2600 | 2800 | 2800 | 2900 | 2900 | 3550 | 5600 |
| Rotation Angle | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 |
| Pump Max Delivery (ltr/min) | 21 | 21 | 24 | 24 | 30 | 30 | 38 | 38 | 57 | 78 |
| Working Pressure (bar) | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 |
| Tank Capacity (ltr) | 35 | 35 | 35 | 35 | 50 | 50 | 50 | 50 | 70 | 70 |
| Digging Bucket | 250+600 | 250+600 | 250+600 | 250+600 | 250+400 | 250+400 | 250+400 | 250+400 | 250+800 | 250+800 |
| Weight With Bucket (kg) | 550 | 570 | 640 | 670 | 770 | 800 | 860 | 890 | 1200 | 1700 |
| Min. Tractor’s Weight (kg) | 1900 | 1900 | 2200 | 2300 | 2500 | 2600 | 2800 | 2900 | 4000 | 6000 |
| Min Power Requirements (hp) | 30 | 30 | 40 | 40 | 60 | 60 | 70 | 70 | 100 | 120 |
| Data/Model | 50 TIX | 55 TIX | 60 TIX | 65 TIX | 70 TIX | 75 TIX | 80 TIX | 85 TIX | 90 TIX | 100 TIX |
|---|---|---|---|---|---|---|---|---|---|---|
| A (mm) | 2100 | 2200 | 2500 | 2600 | 2700 | 2800 | 3000 | 3100 | 3500 | 4200 |
| B (mm) | 1900 | 1900 | 2300 | 2300 | 2500 | 2500 | 2700 | 2700 | 3100 | 3850 |
| C (mm) | 2800 | 2800 | 3200 | 3200 | 3500 | 3500 | 3700 | 3700 | 4200 | 4950 |
| D Working Radius (mm) | 2900 | 2950 | 3270 | 3320 | 3500 | 3550 | 3800 | 3850 | 4000 | 5100 |
| Dimensions Diagram (click to view) | View | View | View | View | View | View | View | View | View | View |
| Travelling Frame Width (mm) | 1400 | 1600 | 1600 | 1800 | 1800 | 2000 | 1800 | 2000 | 2000 | 2000 |
| Bucket Breakout Force (kg) | 2300 | 2300 | 2600 | 2600 | 2800 | 2800 | 2900 | 2900 | 3550 | 5600 |
| Rotation Angle | 180º | 180º | 180º | 180º | 180º | 180º | 180º | 180º | 180º | 180º |
| Pump Max Delivery (ltr/min) | 21 | 21 | 24 | 24 | 30 | 30 | 38 | 38 | 57 | 78 |
| Working Pressure (bar) | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 | 180 |
| Tank Capacity (ltr) | 35 | 35 | 35 | 35 | 50 | 50 | 50 | 50 | 70 | 70 |
| Digging Bucket (mm) | 250÷600 | 250÷600 | 250÷600 | 250÷600 | 250÷400 | 250÷400 | 250÷400 | 250÷400 | 250÷800 | 250÷800 |
| Weight With Bucket (kg) | 550 | 570 | 640 | 670 | 770 | 800 | 860 | 890 | 1200 | 1700 |
| Min Tractor’s Weight (kg) | 1900 | 1900 | 2200 | 2300 | 2500 | 2600 | 2800 | 2900 | 4000 | 6000 |
| Min Power Requirements (hp) | 30 | 30 | 40 | 40 | 60 | 60 | 70 | 70 | 100 | 120 |
